Product datasheet - 120J
Labelled cable tie, clear
110×2,5mm, D=1-20mm, PA6.6, (a*b=9×25mm)
Item number:120J
(EAN: 5997374100274)
110×2,5mm, D=1-20mm, PA6.6, (a*b=9×25mm)
Labelled cable tie, clear
Item number:120J (EAN: 5997374100274)Műszaki adatok: 110×2,5mm, D=1-20mm, PA6.6, (a*b=9×25mm)
More than 10000 pc(s) in stock
Nettó
0.04170 EUR
0.04170 EUR
Bruttó
0.05296 EUR
Vegye meg olcsóbban ezt a terméket
Mennyiség |
Kedvezményes nettó ár |
Megtakarítás |
1000+
|
0.03476 EUR |
0.00694 EUR - 16,64 % |
5000+
|
0.03022 EUR |
0.01148 EUR - 27,53 % |
10000+
|
0.02747 EUR |
0.01423 EUR - 34,13 % |
 |
 |
 |
a
(mm)
|
b
(mm)
|
 |
 |
| 120J |  |
110 × 2.5 mm | 8 | 25 | 1 - 20 mm | 40 N |
Their properties are same as for conventional cable ties, but they have wider heads and necks, does not have teeth, but have a little plastic plate (marking plate). This plate is designed for marking. They are mainly useful, when it is needed to mark the cable bundles. Alcoholic pen or marked foil is suggested for marking.
|
Material:
|
PA 6.6
|
|
Color:
|
clear
|
|
|
Tracon
code
|
L×
S
(mm)
|
a
(mm)
|
b
(mm)
|
Bundle
diameter
(mm)
|
Max. load
(N)
|
|
120J
|
110×2.5
|
9.2
|
20.4
|
1-20
|
40
|
10 N ~ 1 kg; The given data are valid for 23 ± 2 °C temperature, at 50 % relative humidity.
Dimension drawing
