Product datasheet - TR1D1201B4
Contactor
400V, 50Hz, 12A, 5,5kW, 24V DC, 3×NO+1×NC
Item number:TR1D1201B4
(EAN: 5997374229029)
400V, 50Hz, 12A, 5,5kW, 24V DC, 3×NO+1×NC
Contactor
Item number:TR1D1201B4 (EAN: 5997374229029)Technical data 400V, 50Hz, 12A, 5,5kW, 24V DC, 3×NO+1×NC
Ordering in process: 5/10/25
Net
33.46053 EUR
33.46053 EUR
Gross
42.49487 EUR
Rated control supply voltage Us at AC 50HZ:
22.8 -25.2 V
Voltage type for actuating:
DC
Rated operation current Ie at AC-1, 400 V:
25 A
Rated operation current Ie at AC-3, 400 V:
12 A
Rated operation power at AC-3, 400 V:
5.5 kW
Rated operation current Ie at AC-4, 400 V:
5 A
Rated operation power at AC-4, 400 V:
2.5 kW
Type of electrical connection of main circuit:
Screw connection
Number of normally open contacts as main contact:
3
Warranty:
2 year
 |
 |
 AC-3 (A) |
 (kW) |
 |
| TR1D1201B4 | 24 VDC | 12 | 5,5 |
| (A) |
AC-1 | 25 | |
| AC-3 | 12 | ||
| AC-4 | 5 | ||
| (kW) |
220/230 V | AC-3 | 3 |
| 380/400 V | AC-3 | 5,5 | |
| 380/400 V | AC-4 | 2,5 | |
| 415 V | AC-3 | 5,5 | |
| 500 V,660/690 V | AC-3 | 7,5 | |
 |
16 A aM | ||
 |
4 | ||
 |
60 VA | ||
 |
7 VA | ||
| m (mm) | A (mm) | k (mm) | a (mm) | b (mm) | m (35×7,5) |
| 80 | 35 | 71 | 74 | 46 | 117 |
Dimensional drawing
